Díly pro REAR BRAKE CALIPER
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 50213301644 BRAKE CALIPER CPL. REAR L/S |
6 803 Kč | |
| 5 | 54613305200 BRAKE PISTON 34MM |
643 Kč | |
| 6 | 54613318200 REPAIR KIT SEALING RINGS 34MM |
236 Kč | |
| 10 | 54613310200 BOLT SET |
283 Kč | |
| 18 | 54613218000 CUP SET SHORT |
423 Kč | |
| 20 | 60013020000 BLEEDER SCREW WITH CAP |
127 Kč | |
| 25 | 50213025000 HOLLOW SCREW M10X1X19 |
68 Kč | |
| 26 | 42013226000 CU-SEAL RING DIN7603-10X16X1 |
28 Kč | |
| 27 | 42013026000 CU-SEAL RING DIN7603-10X16X1,5 |
28 Kč | |
| 70 | 80013070000 BRAKE HOSE REAR 695MM 04 |
1 551 Kč | |
| 90 | 50313090000 BRAKE PAD REAR TOSHIBA TTH38GF |
1 350 Kč | |
| 90 | 54613309200 BRAKE PAD SET FERIT ID450FF |
830 Kč | |
| 90 | 59013090000 BRAKE PAD SET REAR SINTER 03 |
1 027 Kč |
